A journey to the center of ArchiveLib

So, it’s been a long 3 days at LCA2019 and I’m thinking about doing a lightning talk on my latest project: Machine Embroidery. Specifically, the sizable amount of software acheology that’s been involved in implementing parsing(that still isn’t done) 2 specific embroidery formats VIP and HUS.

This is a rabbit hole; but one I am slowly backing up out of. So here we go.

The formats

Both formats follow the same structure: a header, color information, and 3 sections of compressed stitch data. Let’s take an example file and run through it. The file we’re using stitches this:

![An embroidered Trans pride flag in the shape of the Star Wars Rebel Alliance logo](Rebel Pride.jpg)

So … the header says we have a HUS file with 22972(0x0000_59BC) stitches and 6(0x0000_0006) colours(it’s complicated; but each stripe is a different ‘colour’ even if it was stitched with the same colour thread #creativeLicense). Some other useful stuff for the machine like bounds; but we can skip that stuff. Finally the three offsets: 0x0000_0036, 0x0000_00bc, and 0x0000_09fe.

1
2
3
4
00000000  5b af c8 00 bc 59 00 00  06 00 00 00 52 02 5a 02  |[....Y......R.Z.|
00000010 00 00 dc fe 36 00 00 00 bc 00 00 00 fe 09 00 00 |....6...........|
00000020 00 00 00 00 00 00 00 00 00 00 |..........|
0000002a

For brevity; I’m going to skip the colour parsing because it is just convoluted. Seriously … just write out RGB values. Please.

Now onto the three compressed block; Here is the first one which contains all the information about the stitch attributes(is it a jump stitch, regular, colour change, or the end of the file).

1
2
3
4
5
6
7
8
9
10
00000036  00 8c 53 4c a0 4a d7 fe  9b 1e 93 88 69 6f ff 56  |..SL.J......io.V|
00000046 69 a2 ec 2e 09 1d 3d 0d a0 36 83 14 0e 39 91 09 |i.....=..6...9..|
00000056 a0 d4 46 80 b5 06 f9 59 00 47 23 12 37 36 6f 61 |..F....Y.G#.76oa|
00000066 83 2c dc a3 5a 3e 10 31 de 67 37 19 1c 30 f1 d5 |.,..Z>.1.g7..0..|
00000076 cd d9 ee fa 3a ef 00 00 00 00 ee 8b 2a 85 0e 69 |....:.......*..i|
00000086 97 a8 cf 87 a7 00 2c 88 aa 0c 00 d1 17 55 0c 00 |......,......U..|
00000096 00 00 00 00 00 68 8b 3c 50 13 3e 7b f0 00 00 00 |.....h.<P.>{....|
000000a6 3d 22 ea a1 83 54 45 50 7d 9f ac 63 da 66 5e 60 |="...TEP}..c.f^`|
000000b6 00 03 eb 6d df c0 |...m..|
000000bc

This is mostly garbage to me so onto this compression algorithm

The compression

As described on the reference page this 138 byte block is compressed using a proprietary archive format called Greenleaf ArchiveLib. Not to be confused with libarchive which is a completely different kettle of fish.

This is a compression algorithm that a company could buy the source code for and compile into their applications with any C++ compiler. Judging by this FAQ page archived by WayBack it has a number of benefits over some other algorithms of the age.

But, enough about the product; lets get to some code. Obviously the code exists on the internet; probably by accident. It’s of a old release(version 1.0) released around 1994/1995 but it has the compression algorithm in all its glory:

Oh ... OhSource
1
2
3
4
5
6
7
8
9
10
11
12
13
14
/* ... snip ... */
#define _519 "Incorrect compression level parameter passed to compressor. Compression level = %d"
#define _520 "Memory allocation failure in compression startup"
#define _445(_200,_446)((short )((_446<<_154)^(_278[_200+2]))&(_153-1))
#define _447(_200,_201){short _204;if((_204=_163[_201])!=_157)_164[_204]=\
_200;_164[_200]=_201;_163[_200]=_204;_163[_201]=_200;}
#define _448(s){short _204;if((_204=_164[s])!=_157){_164[s]=_157;_163[_204]\
=_157;}}
RCompress::RCompress(ALStorage&_266, ALStorage&_267, int _269, int _235)
{ _161=&_266; _162=&_267; _531=_235; if(_269>_137||_269<_138){
mStatus.SetError(AL_ILLEGAL_PARAMETER,_519,_269-10); _175=2; }else
_175=(short )(1<<_269); _176=(short )(_175-1); if((_166=new uchar
[_175+_140+2])!=0) memset(_166,0,(_175+_140+2)*sizeof(uchar ));
/* ... snip ... */

Did I say glory; I meant gory. This code is minified, obfuscated C++. Cool. It’s source code. We can make this work.

Oh; side note, I want this embroidery library to be pure Rust, so whilst I could(and did for a time) link against this code, that is not ‘good enough’.

Step 1: Unminifying

So, the first step is to just get some resemblance of indentation; layout; something; anything; please.

It's better?Source
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
/* ... snip ... */
#define _519 \
"Incorrect compression level parameter passed to compressor. Compression " \
"level = %d"
#define _520 "Memory allocation failure in compression startup"
#define _445(_200, _446) \
((short)((_446 << _154) ^ (_278[_200 + 2])) & (_153 - 1))
#define _447(_200, _201) \
{ \
short _204; \
if ((_204 = _163[_201]) != _157) \
_164[_204] = _200; \
_164[_200] = _201; \
_163[_200] = _204; \
_163[_201] = _200; \
}
#define _448(s) \
{ \
short _204; \
if ((_204 = _164[s]) != _157) { \
_164[s] = _157; \
_163[_204] = _157; \
} \
}
RCompress::RCompress(ALStorage &_266, ALStorage &_267, int _269, int _235) {
_161 = &_266;
_162 = &_267;
_531 = _235;
if (_269 > _137 || _269 < _138) {
mStatus.SetError(AL_ILLEGAL_PARAMETER, _519, _269 - 10);
_175 = 2;
} else
_175 = (short)(1 << _269);
_176 = (short)(_175 - 1);
if ((_166 = new uchar[_175 + _140 + 2]) != 0)
memset(_166, 0, (_175 + _140 + 2) * sizeof(uchar));
/* ... snip ... */

Wow, that is so much not any better. The formatting means I can see that I’m looking at some #defines and a function; but besides that I don’t know what _531 is an what it’s doing(spoiler: the int is a lie). Also, because this is all on a C++ class there is no easy differentiator between _531 which is a attribute on this and _137 which is a #defined constant and _269 which is a parameter.

Step 2: Culling

There is a lot of associated code, quite a few #ifdefs and some weird DOS specific flags that were getting in the way; so now that I can see what I’m looking at, I started purging all of them. Huge swathes of code got deleted. I was aiming for the compression algorithm and the smallest amount of auxiliary code to support it.

At the same time I needed to standardize types; In C/C++ land int isn’t an specific size; but in Rust everything is sized exactly, so to save myself some time in the future I changed all the types over; char became uint8_t, short became int16_t and so on.

Step 3: Renaming

Finally; a small enough code base, that still compiles. Lets make it easier to identify the source of each of these variables: #defined variables become CONST_xxx; locals, arguments, functions and the items on the class all get their own prefix:

Getting betterSource
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
/* ... snip ... */
#define MACRO_FN445(arg278, arg200, arg446) \
((int16_t)((arg446 << CONST__154) ^ (arg278[arg200 + 2])) & (CONST__153 - 1))
#define MACRO_FN447(arg163, arg164, arg200, arg201) \
{ \
int16_t macro_local204; \
if ((macro_local204 = arg163[arg201]) != CONST__157) \
arg164[macro_local204] = arg200; \
arg164[arg200] = arg201; \
arg163[arg200] = macro_local204; \
arg163[arg201] = arg200; \
\
#define MACRO_FN448(arg163, arg164, s) \
{ \
int16_t macro_local204; \
if ((macro_local204 = arg164[s]) != CONST__157) { \
arg164[s] = CONST__157; \
arg163[macro_local204] = CONST__157; \
} \
}
RCompress::RCompress(ALStorage &_266, ALStorage &_267, int32_t _269,
int32_t _235) {
_161 = &_266;
_162 = &_267;
_531 = _235;
if (_269 > CONST__137 || _269 < CONST__138) {
mStatus.SetError(AL_ILLEGAL_PARAMETER, _519, _269 - 10);
_175 = 2;
} else
_175 = (int16_t)(1 << _269);
_176 = (int16_t)(_175 - 1);
if ((_166 = new uint8_t[_175 + CONST__140 + 2]) != 0)
memset(_166, 0, (_175 + CONST__140 + 2) * sizeof(uint8_t));
/* ... snip ... */

Step 4: A struct for the data

With my eyes firmly on the Rust prize and a recollection of earlier attempts I knew that a C++ class wasn’t going to translate well … so let’s move all that data into a struct and just re-work some of the allocation. Simple find and replace later and we have a data struct and a basic class to hold onto it.

Step 5: Splitting the problem

At this point much of the auxiliary code was gone and I was left with 8 C++ files; mostly manageable; but the compress file was over 500 lines long at this point and I have this aversion to long files(I tend to get lost easily in them).

Woo. Now I have lots of files with code I don’t understand instead of one big one … wait … how is that better?!

Step 6: Refactoring

Not much to say … I spent a lot of time trying to come up with names for variables that would fit in well with all the references of it; and it was mostly unsuscessfull; but I managed to identify several ‘structures’ and gain enough of an understanding of the algorithm to describe it:

Step 7: Finally, Rust

Overall this was less painful than I had anticipated at the start(and from previous attempts). The work I’d done, especially in the refactoring, had meant I’d gained an understanding of the algorithm so I could un-unsafe it(is that safeify?).

Conclusion

This algorithm is now written purely in Rust; with tests that use the old un-modified C++ version to verify the correctness. I have also take the opportunity to rewrite the expansion algorithm in more idiomatic Rust; the Compression algorithm though eludes my understanding.

You can find the code at archive-rs and it will be on Cargo once I clear up some licensing questions.

So how does the compression algorithm compress?

ArchiveLib generates lookup tables; and then looks up either the byte itself, or the number of bytes to look back in the output to copy from.
